Free Electron
|
#include <ProxMultiGrid.h>
Public Member Functions | |
void | initialize (void) |
virtual unsigned int | detect (sp< Layout > l_pair, sp< RecordGroup > rg_in, sp< RecordGroup > rg_out) |
virtual void | addGrid (Real cellSize) |
Public Member Functions inherited from fe::Component | |
const String & | name (void) const |
Return the components chosen name. More... | |
const String | verboseName (void) const |
Return the annotated chosen name. More... | |
void | setName (const String &name) |
Rename the component to anything you want. More... | |
hp< Registry > | registry (void) const |
Get the Registry that created this component. More... | |
void | adjoin (sp< Component > spComponent) |
Tie this component's lifetime to another. More... | |
sp< Component > | create (const String &implementation, BWORD quiet=FALSE) const |
Convienience function to registry()->create() More... | |
void | disjoin (void) |
Untie component from Hub, if connected. More... | |
String | factoryName (void) |
void | setLibrary (sp< Library > spLibrary) |
Store a reference to the library used to instantiate this component. More... | |
sp< Library > | library (void) |
Get the library that created the component. More... | |
void | setFactoryIndex (I32 a_factoryIndex) |
Set the library's factory index. More... | |
I32 | factoryIndex (void) |
Get the library's factory index. More... | |
void | setSingleton (BWORD set) |
Specify whether component is a singleton. More... | |
BWORD | isSingleton (void) |
Return whether component is a singleton. More... | |
virtual void | acquire (void) |
Specialized reference increment. More... | |
virtual void | release (void) |
Specialized reference decrement. More... | |
Public Member Functions inherited from fe::Handled< Component > | |
const hp< Component > & | getHandle (void) const |
Get a safe handle to this object. More... | |
Public Member Functions inherited from fe::Protectable | |
virtual I32 | protection (void) const |
virtual void | protect (void) |
virtual void | unprotect (void) |
virtual Protectable * | clone (Protectable *pInstance=NULL) |
Public Member Functions inherited from fe::Counted | |
virtual void | acquire (int &rCount) |
Increment the reference count (and get the count) More... | |
virtual void | abandon (void) |
Decrement the reference count. More... | |
int | count (void) const |
Return the count of references. More... | |
void | setName (const String &) |
void | trackReference (void *pReference, String what) |
void | untrackReference (void *pReference) |
void | registerRegion (void *pT, U32 bytes) |
Public Member Functions inherited from fe::Initialized | |
void | initializeAll (void) |
void | setActive (bool a_active) |
Private Types | |
typedef Vector< 3, int > | t_v3i |
typedef std::vector< LocalRecord, StdAllocator< LocalRecord > > | t_lrecords |
Private Member Functions | |
void | add (sp< RecordArray > &ra_in, unsigned int index) |
unsigned int | detect (t_lrecords &a_a) |
unsigned int | detect (t_lrecords &a_a, t_lrecords &a_b) |
unsigned int | detect (Grid &a_ga, Grid &a_gb) |
bool | check (LocalRecord &r_a, LocalRecord &r_b) |
void | setup (sp< Scope > spScope) |
void | setup (Grid &a_grid, SpatialVector &a_extent) |
void | log (void) |
bool | rangeCheck (LocalRecord &r_a) |
Private Attributes | |
sp< Scope > | m_spScope |
AsBounded | m_asBounded |
AsParticle | m_asParticle |
AsProximity | m_asProximity |
Array< Grid > | m_grids |
SpatialVector | m_origin |
sp< SpaceI > | m_spSpace |
SpatialVector | m_boundary |
Array< BaseAccessor > | m_filters |
sp< RecordArray > | m_spPool |
FE_UWORD | m_poolIndex |
hp< Layout > | m_hpPairLayout |
Additional Inherited Members | |
Static Public Member Functions inherited from fe::Counted | |
static String | reportTracker (void) |
static U32 | trackerCount (void) |
Protected Types inherited from fe::Initialized | |
typedef void(* | InitializeFunction) (Initialized *) |
Protected Member Functions inherited from fe::Handled< Component > | |
void | abandonHandle (void) |
Protected Member Functions inherited from fe::Counted | |
int | releaseInternal (void) |
Decrement the reference count. More... | |
void | suppressReport (void) |
Protected Member Functions inherited from fe::Initialized | |
void | addInitializer (InitializeFunction function) |
Related Functions inherited from fe::Component | |
FE_DL_EXPORT void FE_CDECL | checkUnload (sp< Library > &pLibrary, Component *pComponent=NULL) |
Delete the component and unload libraries where appropriate. More... | |
Proximity detection.
The method used partitions space into grids of cells. A separate grid is used for each specified cell size. Cells are cubic; they are the same length in each dimension.
WARNING: this class is by design not reentrant due to the pair pooling.
Note: this class is also a good guide on getting the most speed possible out of the data system.
particle attributes
pair attributes
